Cipherlab 2500 Business Rugged Handheld Barcode Scanner Series
Cipherlab 2500 Series
Business-Rugged Handheld Barcode Scanner
With raising demands for advanced scanning abilities in many industries, such as retail, warehousing and light industry, CipherLab has attentively designed the durable 2500 series handheld scanner to suit various applications in harsh environments. CipherLab 2500 series is able to deliver superior scanning abilities to speed up the efficiency of data collection. Along with business-rugged durability, its high performance is well protected so users can enjoy fast workflow without any worries. Moreover, the 2500 series is also equipped with additional user friendly features to create a productive experience for its users.
CipherLab 2500 series is built for fast and simple deployments such as goods receiving, shipping, inventory checking, work in process and point of sale. It features a high-speed read rate of a snappy 578 scans per second on 1D barcodes. For small or poorly-printed barcodes, the 2500 also guarantees its performance with readability of high-density 3 mil 1D barcodes and 5 mil 2D barcodes. It seamlessly combines its superior scanning performance with IP65 and 1.8 m drop resistance for harsh environments in warehousing and manufacturing. More than just these advantages, its other user-friendly features, like interface auto-detecting, enhanced ESD (electrostatic discharge) protection and swappable battery all make it an optimal choice to update your business to new grounds.
Industry Use:
Warehousing
Retail
Government
| Item | 2500 | 2560 | 2504MR | 2564MR |
|---|---|---|---|---|
| Data capture | Linear Imager | 2D Imager | ||
| Connectivity | Corded | Bluetooth® V4.0 Dual mode (2.1 + EDR/ BLE) | Corded | Bluetooth® V4.0 Dual mode (2.1 + EDR/ BLE) |
| Optical sensor | CCD Linear Sensor 2500 pixels |
CMOS Image Sensor 1280x960 pixels |
||
| Light source | Red LEDs 625 nm (2X) | Warm White LEDs (2x) | ||
| Resolution | 3 mil | 3 mil- 1D barcode / 5 mil - 2D barcode | ||
| Depth of field | Code 39 3 mil: 3 to 10 cm / 1.2 to 3.9 in. Code 39 5 mil: 2 to 14 cm / 0.8 to 5.5 in. UPCA 13mil: 0.5 to 38 cm / 0.2 to 15 in. Code 39 20mil: 1.5 to 60 cm / 0.6 to 23.6 in |
Code 128 5 mil : 18.5 to 37.5 cm / 7.3 to 14.8 in. PDF 417 5 mil: 21 to 26.5 cm / 8.3 to 10.4 in. Data Matrix 7.5 mil: 17 to 35 cm / 6.7 to 13.8 in. Data Matrix 10 mil: 15.5 to 45.5 cm / 6.1 to 17.9 in. UPCA 13 mil: 8 to 94 cm / 3.2 to 37 in. Code 39 100 mil: 28 to 425 cm / 11 to 167.3 in. Data Matrix 160 mil: 29.5 to 384 cm / 11.6 to 151.2 in. |
||
| Scanning angle | Pitch ± 70°, Skew ± 70° | Pitch ± 60°, Skew ± 60° | ||
| PCS | 15% | 25% | ||
| Scan rate | 578 scans/ second | 60 scans/second | ||
| Hands-free scanning | Auto-sense and continuous modes | Auto-sense and presentation modes | ||
| Barcodes supported | Codabar, Code 39, Code 93, Code 128, GS1 DataBar (RSS), Industrial 2 of 5, Interleave 2 of 5, ISBT-128, Italian and French Pharmacodes, Matrix 2 of 5, MSI, Plessey, Telepen, UPC/EAN/GS1-128, and more | 1D: All of the bacodes that 2500 series 1D scanners can support except French Pharmacodes, Plessey and Telepen 2D: PDF417, MicroPDF417, Composite, TLC-39, Datamatrix, QR code, Micro QR code, Aztec, MaxiCode, Han Xin Code Postal Codes: US PostNet, US Planet, UK Postal, Australian Postal, Japan Postal Dutch Postal (KIX) |
||
| Color | Black, Register White | |||
| Size | 16.1 x 6.6 x 9.6 cm / 6.3 x 2.6 x 3.8 in. | |||
| Weight | 145 g / 4.9 oz | 185g / 6.5 oz | 166 g / 5.9 oz. | 198g / 7.0 oz. |
| Impact resistance | 1.8 m multiple drops onto concrete, 1000 (1 m) tumbles. IP65 | |||
| Item | 2504 | 2564 |
|---|---|---|
| Data capture | 2D Imager | |
| Connectivity | Corded | Bluetooth® V4.0 Dual mode (2.1 + EDR/ BLE) |
| Optical sensor | CMOS Image Sensor 1280x800 pixel |
|
| Light source | Warm White LEDs (2x) | |
| Resolution | 3 mil- 1D barcode / 5 mil - 2D barcode | |
| Depth of field | Code 39 3 mil: 4 to 10 cm / 1.6 to 3.9 in. Code 39 5 mil: 3.5 to 17 cm / 1.4 to 6.7 in. UPCA 13 mil: 4 to 28 cm / 1.6 to 11 in. PDF417 5 mil: 3.5 to 10.5 cm / 1.4 to 4.1 in. QR Code 10 mil: 1.5 to 16.5 cm / 0.6 to 6.5 in. |
|
| Scanning angle | Pitch ± 70°, Skew ± 60° | |
| PCS | 25% | |
| Scan rate | 60 scans/second | |
| Hands-free scanning | Auto-sense and presentation modes | |
| Barcodes supported | 1D: All of the bacodes that 2500 series 1D scanners can support 2D: PDF417, MicroPDF417, Data Matrix, QR code, Micro QR Code, Aztec, MaxiCode, Han Xin Code | |
| Color | Black, Register White | |
| Size | 16.1 x 6.6 x 9.6 cm / 6.3 x 2.6 x 3.8 in. | |
| Weight | 145 g / 4.9 oz | 185g / 6.5 oz |
| Impact resistance | 1.8 m multiple drops onto concrete, 1000 (1 m) tumbles. IP65 | |
Key Features
- Business-Rugged Handheld Scanner
- 1D and 2D Options
